★★★★★Gayle G.Nov 25, 2023
I had a hard time finding a doorbell with screws 2.25 inches apart….. although the doorbell is not beautiful, it works fine, looks better than original. The shipping was fast. I am satisfied!
Button Specs
Measurements and mounting details
| Length | 2-13/16" |
|---|---|
| Width | 27/32" |
| Depth | 5/8" |
| Shape | Rectangle |
| Mounting Style | Surface |
| Hole Distance | 2-1/4" |
BS6-W Basic Plastic Lighted Rectangular Doorbell Button by Craftmade
$10.95
The BS6-BZ and BS6-W are rectangular shaped, surface mounted LED doorbell push buttons by Craftmade. Surface mounted wired buttons are very easy to install as it sits directly on top of the surface. The pushbutton is lighted by a LED bulb.
Safe checkout
Encrypted checkout with trusted payment processing
Secure SSL
Low Flat Rate Domestic ShippingExpedited & International ShippingSafe & Secure Checkout30-Day Satisfaction GuaranteeReal Customer SupportQuestions? 800-366-7235
Accessories & Add-Ons
Expand or complete your system with compatible components.
T1610 Craftmade 16V 10VA Wired Doorbell Transformer
T1610
The T1610 Craftmade doorbell transformer provides steady 16V power output for wired doorbell systems. Built with durable cast aluminum construction, this 10VA transformer supports single-chime applications within a 50-foot range. The professional-grade design includes 18-gauge wiring and maintains consistent voltage for dependable operation.
$22.95
0 items selected · Total: $0.00
Buying notes
Is this the right fit?
- Good fit when
- Use this when doorbell wiring is already in place and you want a permanent, battery-free chime.
- Look at another option when
- It is not the easiest choice when there is no usable wiring, when the door is far from the chime, or when receivers are needed in several rooms.
- Range reality
- Check the listed compatibility and placement notes before ordering. Building layout often matters as much as the product rating.
- Setup note
- Check the existing transformer, button, and chime compatibility before replacing parts. Video doorbells may need more transformer capacity than an older chime did.
The BS6 series of lighted wired buttons by Craftmade are standard wired buttons that are constructed of ABS plastic and are available in two different finishes, bronze and white. These are easy-to-mount buttons as they are surface mounted directly on top of the surface you want to mount them to. This means you do not have to recess the unit inside the wall or door frame.
The buttons are manufactured by Craftmade and come with a one year manufacturer's warranty. They are lighted by an LED bulb that lasts a lifetime and will never get hot.
- Surface mount
- LED lighted
- ABS plastic
- Available in white or bronze colors
- Manufactured by Craftmade
- One year manufacturer's warranty
- Button dimensions are 0.88'W x 2.88'H x 0.75''D
- The mounting hole to mounting is 2.25''
Simple Surface-Mount Replacement Button
The BS6 lighted wired doorbell button is a practical replacement when you need a clean, inexpensive button without changing the wired chime system. Surface mounting makes it useful on narrow trim, siding blocks, utility doors, rental properties, and service entries where a recessed button would add unnecessary work.
What to Check
Confirm low-voltage wired doorbell wiring and choose the finish that best matches the entry hardware. This is a good basic lighted push button for everyday repairs, especially when the old plastic button is cracked, yellowed, or no longer lights consistently.
| Brand | Craftmade |
|---|---|
| Button Mount Style | Surface |
| Button Shape | Rectangular |
| Condition | New |
| Country Of Origin | China |
| Finish | Bronze, Flat Black, White |
| Lighted Button | Lighted Button |
| Product Dimensions | 0.75L x 0.88W x 2.88H |
| Warranty | 1 Year |
Specifications
| Brand | Craftmade |
|---|---|
| Button Mount Style | Surface |
| Button Shape | Rectangular |
| Condition | New |
| Country Of Origin | China |
| Finish | Bronze, Flat Black, White |
| Lighted Button | Lighted Button |
| Product Dimensions | 0.75L x 0.88W x 2.88H |
| Warranty | 1 Year |
Reviews
5.00
★★★★★
8 verified reviews
★★★★★Thomas P.Apr 5, 2023
It’s not flush mounted as it still needs a hole for the back of the button but I got it to work misleading information
★★★★★Roxanne B.Jun 21, 2022
Very satisfied with this purchase
★★★★★Thomas J.Dec 20, 2020
Received the door bell today. Easy install. Received the door bell in about a week. Great service.
★★★★★Leo P.Nov 14, 2020
Exactly what I wanted. Works well.
★★★★★SchultzSep 26, 2018
Love my new doorbell. It is nice to know that it will last a long time .
★★★★★Mr. W.Aug 25, 2018
Are you gonna pull those pistols or whistle Dixie? This door bell pulls the pistols.
★★★★★ONOFRIO F.May 28, 2018
I received 2 bronze push buttons that did NOT say LED or LIGHTED on the packaging. My first thought was I received the wrong item. I called the vendor and questioned. The lady checked with her supplier and said that "it is a LIGHTED-LED pushbutton." I thanked her but, I was still doubtful. I took one of the pushbuttons apart and sure enough, there WAS a pinhead size LED soldered inside the backplate of the pushbutton. The inside has 2 very sturdy spring-type contacts which allow the button to be pushed at the top or bottom for a positive contact. Bottom line, the BS6-BZ lighted LED push button works as advertised and is of high quality.
Q&A
Questions & Answers
Answers from our team for BS6-W Basic Plastic Lighted Rectangular Doorbell Button by Craftmade.
BS6-W can you give me the actual dimensions of the push button (actual size of the button not the entire mechanism). I have a cover that I would like to keep if I can get the correct size button to fit inside?
The button for the BS6-W measures 1 1/4 inches.
Answered for TAMMY S.
I'm replacing an existing surface mount doorbell. What is the exact distance in inches between the screw holes?
The screw holes are 2 1/4 " apart
Answered for Jeannette N.
It appears only the depth and width dimensions are provided. What is the height (the dimension of the housing when installed from bottom to top)?
Sorry about missing that. We have updated the website. The dimensions are: Length: 0.75 in. Width: 0.88 in. Height: 2.88 in.
Answered for Keith
Do these have two wires? I need a doorbell that has a light.
Good afternoon. Yes, the BS6 push button has two wires, each wire would be connected to a terminal on the button and it is lighted by a LED bulb.
Answered for Sandy
Manuals & Resources
Product support documents
Download product manuals and preview sound libraries for installation, pairing, and troubleshooting.
Read the manual onlinecraftmade two note door chime manual
Download the PDF resource for setup, product details, and support reference.
- Installation and setup steps for this product.
- Pairing, placement, and receiver or transmitter setup notes.
- Wiring, power, mounting, or accessory connection details.
