SaleButton Specs
Measurements and mounting details
| Length | 2-15/16" |
|---|---|
| Width | 2-15/16" |
| Depth | 13/16" |
| Shape | Square |
| Mounting Style | Concealed/Recessed |
| Hole Distance | 2-1/16" |
PB5016 Craftmade Lighted Doorbell Button - Square Shaped with Straight Lines
$15.95$19.95
The Craftmade PB5016 is a lighted square doorbell button with a clean face, concealed mounting screws, and a dark espresso finish. It works well when you want a wired button that looks sharper than the basic builder-grade options.
Safe checkout
Encrypted checkout with trusted payment processing
Secure SSL
Low Flat Rate Domestic ShippingExpedited & International ShippingSafe & Secure Checkout30-Day Satisfaction GuaranteeReal Customer SupportQuestions? 800-366-7235
Accessories & Add-Ons
Expand or complete your system with compatible components.
T1610 Craftmade 16V 10VA Wired Doorbell Transformer
T1610
The T1610 Craftmade doorbell transformer provides steady 16V power output for wired doorbell systems. Built with durable cast aluminum construction, this 10VA transformer supports single-chime applications within a 50-foot range. The professional-grade design includes 18-gauge wiring and maintains consistent voltage for dependable operation.
$22.95
CBR-DW Craftmade Tapered Wired Doorbell in Two Color Choices
CBR
CBR-DW is a tapered wired door chime from Craftmade offered in designer white and classic white. It is a straightforward choice for shoppers who want a cleaner-looking hardwired chime with a little more shape than a flat standard cover.
$24.95
0 items selected · Total: $0.00
Buying notes
Is this the right fit?
- Good fit when
- Use this when the existing wired doorbell system works and you are replacing the outside button for fit, finish, lighting, or weather exposure.
- Look at another option when
- The chime does not ring even with the old button's two wires touched together. That points to the transformer or the chime, not the button. If you want a lighted button, check that the existing chime is the mechanical type most lighted buttons need.
- Mounting and fit
- This button is listed as concealed mount. Surface-mount buttons sit on top of the trim or siding with the wires through a small hole behind them. Flush or recessed buttons drop into a cutout so the faceplate sits closer to the wall. Compare the mounting style, faceplate size, and screw spacing with the old button so the new one covers the old footprint and lines up with the existing holes.
- Setup note
- Turn off power to the low-voltage circuit, note which wire went to which terminal on the old button, then move the two wires to the new button's screw terminals and mount it with the included screws.
The PB5016 in espresso is a surface-mount wired doorbell button with a square profile and straight-line styling that suits newer trim packages, darker hardware, and simple entry details. One of its better design choices is the hidden screw layout, which keeps the face cleaner than many older push buttons that leave the hardware exposed.
Craftmade builds this model with an illuminated center button so visitors can find it more easily in the evening. The listed footprint is about 2-15/16 inches square with a depth near 13/16 inch, and the standard hole spacing helps when you are replacing an older wired button without rebuilding the trim. If measurements are the sticking point, our wired push-button measurement guide is a useful check before ordering.
If you want to compare this shape with round, arched, or more traditional styles, browse the full wired buttons category.
Square Lighted Button with Hidden-Fastener Styling
The PB5016 Craftmade wired push button is a good exterior upgrade when you want a square, modern button face with a cleaner finished look. The hidden screw design helps the button feel more intentional on front entries, side doors, and trim with darker or contemporary hardware.
Before You Replace the Old Button
Measure the existing opening and mounting surface so the square face sits cleanly. This product fits searches for a square lighted doorbell button and should be compared by finish, size, and wired-system compatibility.
Specifications
| Brand | Craftmade |
|---|---|
| Button Mount Style | Concealed, Recessed |
| Button Shape | Square |
| Finish | Espresso, Flat Black, Pewter |
| Lighted Button | Lighted Button |
| Warranty | 1 Year |
| Door Count | Single-Door |
Reviews
5.00
★★★★★
4 verified reviews
★★★★★Robert I.Sep 14, 2022
I'm very pleased with this unit and it's a good value. It is well made and seems to be very durable. The lighted button is a nice touch too. It adds a nice modern touch to my home.
